EN - 5
English
Hardware Installation
3
Remove the black cover as shown below so that you can ne-tune the focus and zoom the
camera later when the cabling is done.
50
50
5m
41
41
5m
Before installing your camera,
make sure the built-in PIR (Passive
Infrared Sensor) can be directed
toward the area of interest, where
possible intrusion may occur. (The
sensitivity of PIR sensor depends
on the object size and temperature
differences between the object and
the background environment.)
Dome Cover
Bottom of the
Camera
Tilt Ajustment
Screw
Focus Ctrl
Zoom Ctrl
Top View
Side View
To Next Page
