EN - 4
Mounting the Network Camera - Ceiling or Wall Mount
1. Use the alignment sticker as a template to mark where holes will be drilled on the ceiling. Drill two
holes into the ceiling; and hammer in the plastic anchors.
2. Drill another hole if you want to route cables through the ceiling or wall.
3. Connect and route an Ethernet cable through the ceililng or wall.
4. Temporarily attach the Network Camera to the ceiling using two included screws.
2
3
1
4
NOTE:
1. Do not completely tighten the mounting screws
in the screw slots yet. You may need to turn the
camera left or right for a best shooting direction
later.
2. The camera can only be powered by PoE. There
is no DC or AC input connector.
Routing hole
position
5. After tuning the camera's shooting direction
and tilt angle, you can remove the camera and
drill another 2 holes to the ceiling for better
support. For vandal-proof applications, you can
secure the camera
using all 4 mounting holes.
To Next Page
