Vivotek FD8151V Quick Installation Guide

EN - 3
English
Hardware Installation
3
Removing the Dome Cover
1. Unscrew the anit-tamper screws using the
included screwdriver.
2. Remove the dome cover.
3. Remove the slide cover if you want to route
cables from the side of camera instead of a
hole on the ceiling or wall.
0002D10766AD
FD8151V-F2
1. Record the MAC address before installing
the camera.
IMPORTANT:
1. It is recommended to use an Ethernet cable that
comes without the strain relief boot. You can
remove the boot if your cable comes with one.
Strain relief boot
NOTE:
<RXFDQFKHFNWKHPRGHOQDPHVXI¿[IRUWKH
type of lens mounted on your camera. The
applicable lens can be:
F2: 2.4mm; F4: 4mm; F8: 8mm. The shorter
the focal length, the wider the view.
2. As shown below, you may also route cable from
the side.
