Vivotek FD8161 Quick Installation Guide

EN - 6
General Connection (without PoE)
1. If you have external devices such as sensors and alarms, connect them to the general
I/O terminal block.
2. Connect the camera to a switch via Ethernet cable.
3. Connect the power cable from the Network Camera to a power outlet.
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
2
3
Ethernet Switch
Network Deployment
4
1: Power
2: Digital output
3: Digital input
4: Ground
Audio In
1 2 3 4
AV Out
ON
Int. NTSC
1 2
Ext PAL
1
Installation Tips
