48 - User's Manual
Image settings
On this page, you can tune the White balance, Image adjustment and WDR enhanced parameters. You
can congure two sets of preferred settings: one for normal situations, the other for special situations,
such as day/night/schedule mode.
White balance: Adjust the value for the best color temperature.
■ You may follow the steps below to adjust the white balance to the best color temperature.
1. Place a sheet of paper of white or cooler-color temperature color, such as blue, in front of the lens,
then allow the Network Camera to automatically adjust the color temperature.
2. Click the Fix current value and conrm the setting while the white balance is being measured.
■ You may also manually tune the color temperature by pulling the RGain and BGain slide bars.
Image Adjustment
■ Brightness: Adjust the image brightness level, which ranges from 0% to 100%.
■ Contrast: Adjust the image contrast level, which ranges from 0% to 100%.
■ Saturation: Adjust the image saturation level, which ranges from 0% to 100%. You can also select
Customize and manually enter a value.
