54 - User's Manual
Media > Video
Stream settings
Please follow the steps below to set up those settings for an individual stream:
1. Select a stream to congure its viewing region.
2. Choose a proper Frame Size from the drop-down list according to the size of monitored device.
3. Select the Maximum frame rate.
■ The parameters of a xed-focal lens' multiple streams:
Region of Interest Output frame size
Stream 1 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 2 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 3 xed xed
To begin the conguration, rst select a video channel.
To change the frame size, frame rate, and other related settings, click on video settings for a video
stream to its individual conguration panel.
Click Viewing Window to open the viewing region settings page. On this page, you can congure the
Region of Interest and the Output Frame Size for a video stream. For example, you can crop only a
portion of the image that is of your interest, and thus save the bandwidth needed to transmit the video
stream. As the picture shown below, the area of your interest in a parking lot should be the vehicles. The
blue sky is of little value for the surveillance purpose.
