VIVOTEK
200 - User's Manual
action_do_i<0~(ndo-1)
>_enable
0, 1 0 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1)
>_duration
1~999 1 6/6 Duration of the digital output trigger in
seconds.
action_goto_enable <Boolean> 0 6/6 Enable/disable ptz goto preset position
on event triggered.
action_goto_name string[40] <blank> 6/6 Specify the preset name that ptz goto on
event triggered.
action_cf_enable <Boolean> 0 6/6 Enable or disable sending media to SD
card.
action_cf_folder string[128] <blank> 6/6 Path to store media.
action_cf_media 0~4, 101 <blank> 6/6 Index of the attached media.
action_cf_datefolder <boolean> 1 6/6 Enable this to create folders by date,
time, and hour automatically.
action_cf_backup <Boolean> 0 6/6 Enable or disable the function that send
media to SD card for backup if network is
disconnected.
action_server_i<0~4>_e
nable
0, 1 0 6/6 Enable or disable this server action.
action_server_i<0~4>_
media
NULL, 0~4 <blank> 6/6 Index of the attached media.
action_server_i<0~4>_
datefolder
<boolean> 0 6/6 Enable this to create folders by date,
time, and hour automatically.
action_patrol_enable
(only for VS series)
<product dependent>
<Boolean> 0 6/6 Enable/disable ptz patrol when event
triggered.
action_ patrol _server
(only for VS series)
<product dependent>
0~255 0 6/6 Indicate the target servers to which the
snapshots taken during patrol dwelling
time should be sent.
One bit represents one application server
(server_i0~i4).
bit0 (LSB) = server_i0.
bit1 = server_i1.
bit2 = server_i2.
bit3 = server_i3.
bit4 = server_i4.
For example, enable server_i0,
server_i2, and server_i4 as notification
servers; the notifyserver value is 21.
