VIVOTEK
120 - User's Manual
range from 100 to 900 Megabytes.
■ File name prex: Enter a name for each recorded video.
If you want to enable recording notication, please click Event
to set up. Please refer to Event > Event
settings on page 99 for more details.
When completed, select Enable this recording. Click Save to enable the setting and click Close to exit
this page. When the system begins recording, it will send the recorded les to the network storage or SD
card. The new recording name will appear on the recording page as shown below.
To remove an existing recording setting from the list, single-click to select it and click Delete.
■ Video (Name): Click to open the Recording settings page to modify.
■ ON (Status): Click to manually adjust the Status. (ON: start recording; OFF: stop recording)
■ NAS or SD (Destination): Click to open the le list of recordings as shown below. For more information
about folder naming rules, please refer to page 109 for details.
To Next Page
