Pixel Calculator
Advanced Mode
Click the Add button at the lower screen to create a pixel calculator window. Place your cursor on the
window to move it to an area of your interest, and change the size of window to t the area of interest.
Once they are drawn, the numbers of pixels of the sides of windows will appear. This allows you to
calculate if your current conguration fullls a requirement, for instance, recognizing the faces of persons
passing through a location. A facial recognition usually requires around 130 pixels per meter or higher.
1
2
Pixel Calculator
Pixel Calculator
The pixels thus calculated is listed at
the lower screen on a per-stream basis
depending on the frame size you congure
for each video stream.
