Vivotek FE8172 User Manual

VIVOTEK
170 - User's Manual
7.27 Privacy mask
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable privacy mask.
win_i<0~4>_enable <boolean> 0 4/4 Enable privacy mask
window.
win_i<0~4>_name string[14] <blank> 4/4 Name of the privacy mask
window.
win_i<0~4>_
polygon
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240
0 4/4 Coordinate of polygon
window position.
(4 points:
x0,y0,x1,y1,x2,y2,x3,y3)
7.28 Capability
Group: capability
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
api_httpversion <string> 0100a 0/7 The HTTP API version.
bootuptime <positive
integer>
60 0/7 Server bootup time.
nir 0,
<positive
integer>
0 0/7 Number of IR interfaces.
(Recommand to use ir for
built-in IR and extir for
external IR)
npir 0,
<positive
integer>
0 0/7 Number of PIRs.
ndi 0,
<positive
integer>
1 0/7 Number of digital inputs.
nvi 0,
<positive
integer>
3 0/7 Number of virtual inputs
(manual trigger)
ndo 0,
<positive
1 0/7 Number of digital outputs.
