VIVOTEK
User's Manual - 13
Hardware Installation - FE8181V
Opening Dome Cover
Please refer to page 20 for the installation details of the FE8181.
Rubber Stopper on the hole
for Power & IO Cables
Tamper-proof Screw
Rubber Seal Plug on the hole for
RJ45 Ethernet Cable
First, use the supplied screwdriver to loosen the four screws and detach the dome cover from
the camera base. Then, follow the steps below to install the camera to either a ceiling or a wall.
Remove the stoppers and route cables through
the openings.
WARNING:
Due to its high performance IR lights, the surface temperature of the dome cover can reach
70ºC after operating in the night mode for a period of time. You should then wait for the surface
to cool down if you should need to re-install the camera.
To Next Page
