Technical Specications
Models FE8191
FE8391-V
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 256 MB
RAM 1GB
Camera Features
Image Sensor 1/2.3" Progressive CMOS in 4072x3046
Maximum Resolution 2944x2944
Lens Type Fixed-focal
Focal Length F=1.5 mm
Aperture F2.8
Field of View 180° (horizontal)
180° (vertical)
180° (diagonal)
Shutter Time 1/5 sec. to 1/8,000 sec.
WDR Technology WDR Enhanced
Day/Night Removable IR-cut filter for day & night function
Minimum Illumination 0.75 Lux, 30 IRE (Color)
<0.01 Lux, 30 IRE (BW)
Preset Locations 20
Pan/tilt/zoom Functionalities ePTZ: 12x digital zoom
IR Illuminators Built-in IR illuminators, effective up to 10 meters
with Smart IR (FE8391-V)
IR LED*6 (FE8391-V)
On-board Storage MicroSD/SDHC/SDXC card slot
Video
Compression H.264, MJPEG
Maximum Frame Rate 12 fps @ 2944x2944
Maximum Streams 4 Simultaneous Streams
S/N Ratio 56dB
Dynamic Range 60dB
Video Streaming Adjustable resolution, quality and bitrate
Configurable video cropping for bandwidth saving
Image Settings Time stamp, text overlay, flip & mirror, scheduled profile
settings, configurable brightness/contrast/saturation/
sharpness,, pixel calculator, 3D-Noise reduction, 2D-Noise
reduction, white balance, exposure control, gain, backlight
compensation, privacy masks
Audio
Audio Capability Audio input/output (full duplex)
Compression AAC, G.711, G.726
Interface Built-in Microphone
External Microphone input
External Line output
Effective Range 5 meters
Network
Users Live viewing for up to 10 clients
Protocols IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP,
802.1X
Interface 10Base-T/100 BaseTX Ethernet (RJ-45)
ONVIF Supported, specification available at www.onvif.org
Intelligent Video
Video Motion Detection 5 window video motion detection
Technical Specifications
Compatible Accessories
Alarm and Event
Alarm Triggers Motion detection, manual trigger, digital input, periodical
trigger, system boot, recording notification, camera
tampering detection, audio detection
Alarm Events Event notification using digital output, HTTP, SMTP, FTP and
NAS server
General
Connectors RJ-45 for Network/PoE connection
Audio input *1
Audio output *1
DC 12V Power input
Digital input *1
Digital ouput *1
LED Indicator System power and status indicator
Power Input 12V DC
IEEE 802.3at PoE Class 4
Power Consumption FE8191: DC12V 11.2W/POE 12.3W
FE8391-V: DC12V 21.7W/POE 23.4W
Dimensions FE8191: Ø: 160 x 39.4 mm
FE8391-V: Ø: 160 x 51.2 mm
Weight FE8191: 597 g
FE8391-V: 805 g
Casing Weather-proof IP66-rated housing (FE8391-V)
Vandal-proof IK10-rated metal housing (FE8391-V)
Safety Certifications FE8191: CE, LVD, VCCI, C-Tick, UL, FCC Class B
FE8391-V: CE, LVD, VCCI, C-Tick, UL, FCC Class A
Operating Temperature F E 8191:
Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F)
Working Temperature: -10°C ~ 50°C (14°F ~ 122°F)
FE8391-V:
Starting Temperature: -25°C ~ 50°C (-13°F ~ 122°F)
Working Temperature: -40°C ~ 50°C (-40°F ~ 122°F)
Warranty 36 months
System Requirements
Operating System Microsoft Windows 7/Vista/XP/2000/8
Web Browser Mozilla Firefox: 7 or above (streaming only)
Chrome: 17 or above (streaming only)
Safari: 5.1.4 or above (streaming only)
Internet Explorer 7.x, 8.x, 9.x, 10, 11
Other Players VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
CD User's manual, quick installation guide, Installation Wizard
2, ST7501 32-channel, VAST CMS (90-day free trial version),
Calibration Tool
Others Quick installation guide, warranty card, alignment sticker,
waterproof connector, desiccant bag, RJ45 coupler, software
CD, Cable management bracket (FE8391-V)
Dimensions
Ø160 mm Ø160 mm39 mm 51 mm
• FE8191 • FE8391-V
Mounting Kits
AM-51A/AM-520
Dome adapter
A M -116 /A M -117
Pendant pipe
A M -114/A M -118
Pendant head
AM-517
Adapter Ring
