Physical Description - FE8391V
Inner View
Header (J7)
Contacts (A)
Lens
Header (J6)
Ethernet 10/100 RJ45 Socket
i
Align (B) to (A) when attaching
the dome cover
Contacts for IR units (B)
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
