D. Technical specifications
- System
CPU: Vivotek VVTK-1000
RAM: 32MB SDRAM
ROM: 4MB FLASH ROM
- Networking
Protocol
TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, Telnet, NTP, DNS,
DHCP and RTSP
Physical
10 baseT or 100 baseT Fast Ethernet auto negotiation
- Video
Algorithm supported
MPEG4(simple profile) for streaming video
JPEG for still image
Features
Adjustable image size, quality and bit rate
Time stamp and text overlay
3 motion detection windows
Resolution
Up to 30/25 frames at 160x120
Up to 30/25 frames at 320x240
Up to 30/25 frames at 640x480
- Camera Specification
1/4 inch color CMOS sensor
Resolution: 640x480
1.5Lux/F2.0
AGC, AWB, AES
Electronic shutter: 1/60 ~ 1/15000 second
- Lens
Fixed focal with fine tuning, 4.0mm, F2.0
- Audio
AAC, GSM-AMR
- Microphone
Omni-directional
Frequency: 50 – 16000Hz
S/N ratio: more than 60dB
- LED indicator
Dual color status indicator
- Dimension
35mm (D) * 107mm (W) * 76mm (H)
- Weight
NET. 170g
- Power
Input: 100-240VAC, 50/60Hz, 0.5A
Output: 5VDC, 2A
- Operating Environment
Temperature: 0-50°C/32-122°F
Humidity: 95%RH
- EMI & Safety
CE, FCC
- Viewing system requirement
Operating system
Microsoft Windows 98SE/ME/2000/XP
Browser
Internet Explorer 5.x or above
