Power Cord
Socket
Indented Reset
Button
Ethernet 10/100
RJ45 Socket
MIC In
Wireless Antenna
Connector
Audio Out
General I/O
Terminal Block
IP7138IP7138
Router
Alarm and Event Management
．Triple-window video motion detection
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP, or FTP
．Local recording of MP4 file
Local Storage
．Compact Flash card slot
．Stores snapshots and video clips
Security
．Multi-level user access
．IP address filtering
Users
．Camera live viewing for up to 10 clients
Dimensions (including lens)
．177 mm (D) x 96�2 mm (W) x 47�4 mm (H)
Weight (including lens)
．Net: 276 g (IP7138)
．Net: 292 g (IP7139)
LED Indicator
．System power and status indicator
．System activity and network link indicator
Power
．12V DC
．Power consumption: 4�4 W (IP7138)
．Power consumption: 4�9 W (IP7139)
．802�3af compliant Power over Ethernet
Approvals
．CE, LVD, FCC, VCCI
Operating Environments
．Temperature: 0° ~ 50° C ( 32° ~ 122° F)
．Humidity: 20 % ~ 80 % RH
Viewing System Requirements
．OS: Microsoft Windows 2000/XP/Vista
．Browser: Mozilla Firefox, Internet Explorer 6.x or above
．Cell phone: 3GPP player
．Real Player: 10�5 or above
．Quick Time: 6�5 or above
Installation, Management, and Maintenance
．Installation Wizard 2
．16-CH recording software
．Supports firmware upgrade
Application
．SDK available for application development and system integration
Alarm and Event Management
．Triple-window video motion detection
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP, or FTP
．Local recording of MP4 file
Local Storage
．Compact Flash card slot
．Stores snapshots and video clips
Security
．Multi-level user access
．IP address filtering
Users
．Camera live viewing for up to 10 clients
Dimensions (including lens)
．177 mm (D) x 96�2 mm (W) x 47�4 mm (H)
Weight (including lens)
．Net: 276 g (IP7138)
．Net: 292 g (IP7139)
LED Indicator
．System power and status indicator
．System activity and network link indicator
Power
．12V DC
．Power consumption: 4�4 W (IP7138)
．Power consumption: 4�9 W (IP7139)
．802�3af compliant Power over Ethernet
Approvals
．CE, LVD, FCC, VCCI
Operating Environments
．Temperature: 0° ~ 50° C ( 32° ~ 122° F)
．Humidity: 20 % ~ 80 % RH
Viewing System Requirements
．OS: Microsoft Windows 2000/XP/Vista
．Browser: Mozilla Firefox, Internet Explorer 6.x or above
．Cell phone: 3GPP player
．Real Player: 10�5 or above
．Quick Time: 6�5 or above
Installation, Management, and Maintenance
．Installation Wizard 2
．16-CH recording software
．Supports firmware upgrade
Application
．SDK available for application development and system integration
Models
．IP7138 (PoE)
．IP7139 (WLAN)
System
．CPU: VVTK-1000 SoC
．Flash: 8MB
．RAM: 64MB
．Embedded OS: Linux 2�4
Lens
．CS mount, f=6�0 mm, F1�8, Fixed
Shutter Time
．1/2 sec� to 1/10000 sec�
Image Sensor
．1�3M-Pixel CMOS sensor in VGA resolution
Minimum Illumination
．2�7 Lux@F1�8
Video
．Compression: MJPEG & MPEG-4
．Streaming:
Simultaneous dual-streaming
MPEG-4 streaming over UDP, TCP, or HTTP
MPEG-4 multicast streaming
MJPEG streaming over HTTP
．Supports 3GPP mobile surveillance
．Frame rates:
MPEG-4: Up to 30/25 fps at 640x480
Up to 7�5 fps at 800x600
MJPEG: Up to 30/25 fps at 640x480
Up to 7�5 fps at 1280x1024
Image Settings
．Adjustable image size, quality, and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness、sharpness、contrast、and saturation
．AWB, AES
Audio
．Compression:
GSM-AMR speech compression, bit rate: 4�75 kbps ~12�2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps ~128 kbps
．Interface:
Built-in microphone
External microphone input
．Supports two-way audio by SIP protocol
．Supports audio mute
Networking
．10/100 Mbps Ethernet, RJ-45
．802�11b/g WLAN (IP7139)
．Protocols: TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP, SMTP,
FTP, DHCP, NTP, DNS, DDNS, and PPPoE
P/N: 011000201 Ver 2�0
System Overview
Specifications
PC with
Recording Software
All specications are subject to change without notice. Copyright 2008 VIVOTEK INC. All rights reserved.
