VIVOTEK
190 - User's Manual
7.13 Exposure window setting per channel
Group: exposurewin_c<0~(n-1)> for n channel products
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
mode auto, custom,blc auto 4/4 The mode indicates how to decide
the exposure.
auto: Use full view as the only
one exposure window.
custom: Use inclusive window.
blc: Use BLC.
win_i<0~9>_enable <boolean> 0 4/4 Enable or disable the window.
win_i<0~9>_policy 0~1 0 4/4 1: Indicate inclusive.
win_i<0~9>_home <coordinate> (110,80) 4/4 Left-top corner coordinate of the
window.
win_i<0~9>_size <window size> (100x75) 4/4 Width and height of the window.
Group: exposurewin_c<0~(n-1)>_profile for m profile and n channel product
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
i<0~(m-1)>_mode auto,
custom,blc
auto 4/4 The mode indicates how to
decide the exposure.
auto: Use full view as the
only one exposure window.
custom: Use inclusive
window.
blc: Use BLC.
i<0~(m-1)>_win_i<0~9>_enable <boolean> 0 4/4 Enable or disable the
window.
i<0~(m-1)>_win_i<0~9>_policy 0~1 0 4/4 1: Indicate inclusive.
i<0~(m-1)>_win_i<0~9>_home <coordinate> (110,80) 4/4 Left-top corner coordinate of
the window.
i<0~(m-1)>_win_i<0~9>_size <window size> (100x75) 4/4 Width and height of the
window.
