VIVOTEK
6 - User's Manual
Specications
Model Number IP816A-LPC enclosure
Power Input 24VAC (+/-10%)
Rating Current 3.5 A
Heater Control 15°C (ON) / 25°C (OFF)
Blower Control 35°C (ON) / 25°C (OFF)
Environmental Operation
Temp.
AE-237 Single heater: -20°C ~ +50°C
AE-236 Double heater: -40°C ~ +50°C (heater is on at -40°C. When temperature
reaches -10°C, camera is powered on)
Protection Level IP66, IK10
Temper Glass thickness 4mm
Mounting Bracket Fully-cable Management
Construction Die-cast Aluminum Alloy
Coating White epoxy powder coating
Dimensions 400 (L) x 130 (W) x 108 (H) mm
Net Weight 2900g
IR light angle of beam
(different IR light units)
AI-104-010 Street: 10º
Mounting Conguration & Dimensions
Swivel Positions and Directions
171
256
462.7
