VIVOTEK
64 - User's Manual
you select the Video Rotation mode in Media > Video window. See page 75 for more information.
Rotate -
MirrorNormal Flip Rotate 90°
clockwise
The camera may be installed on a vertical, side-facing, or tilted surface in order to accommodate
the interior or exterior design of a vehicle or building. Because the interior of a transportation
vehicle is often shaped as a narrow rectangular space, the conventional HD image, such as that
of a 16:9 aspect ratio, will be incongruous with its wide horizontal view. With video rotation, the
camera can more readily cover a tall and narrow eld of view.
The rotation here indicates clockwise
rotation. Rotation can be applied with ip,
mirror, and physical lens rotation settings
to adapt to different mounting locations.
The figures in the illustration are shown
in a consecutive order.
The rotation mode is disabled with the
LPC application.
