VIVOTEK
User's Manual - 69
E-Patrol Settings
You can select some preset positions for the Network Camera to patrol�
Please follow the steps below to set up a patrol schedule:
1� Click a preset location on the list and click Select�
2� The selected preset location will be displayed on the Source list�
3� Set the Dwelling time for the preset location during auto patrol� You can also manually enter a value
in the blank and click Update�
4� Repeat step 1 and 3 to select additional preset locations�
5� If you want to delete a selected location, select it from the Source list and click Remove�
6� Select a location and click Up or Down to rearrange the patrol order�
7� Click Save to enable the settings�
2010/05/26 11:46:50
1
2
6
5
7
3
To Next Page
