EN - 3
English
First, use the supplied screwdriver to detach the dome cover from the camera base. Insert your
MicroSD/SDHC Card if necessary.
Dome Cover
Hardware Installation
3
Tamper-proof Screw
Camera Base
Plastic Cover
2
1
RJ45 Cable Dimension
2. Strip part of the sheath from the Ethernet
cable.
1. Drill a hole on the rubber seal plug and insert
an Ethernet cable through the opening.
Rubber Seal Plug
Assembling Steps
Recommended cable diameter: 5 to 8mm (Use CAT5e only)
3.1 Connecting RJ45 Ethernet Cable
To Next Page
