Vivotek SD8333-E - Page 154

VIVOTEK
154 - User's Manual
irismanual 1~13
(F14~F1.6)
13 4/4 Iris adjustment
(exposurecontrol => manual)
shutterspeed 0~14
(1/1 ~ 1/10000)
5 4/4 Exposure time
(exposurecontrol => manual)
gain 0~15
(0db ~ 28db)
5 4/4 Gain control
(exposurecontrol => manual)
whitebalance auto,
indoor,
outdoor,
outdoorauto,
rbgain,
sodium,
sodiumauto,
sodiumoutdooaut
o,widerange,
manual
outdoor 4/4 “auto” indicates auto white
balance.
“indoor”– 3200k base mode
“outdoor”- 5800k base mode
“outdoorauto” - auto white
balance mode specifically for
outdoors.
“rbgain”- manual set rgain/bgain
“sodium” - sodium vapor lamps.
“Sodiumoutdooauto”-Sodium
Vapor Lamp Outdoor Auto
“Widerange” - Auto Tracing White
balance (2000K to 10000K)
“manual” – keep current value
fixvalenable 0~2 0 4/4 indicates keep current value.
0: disable, 1: enable,
2: trigger/get current value
rgain 0~100 30 4/4 Manual set rgain value of gain
control setting.
bgain 0~100 30 4/4 Manual set bgain value of gain
control setting.
defog 0, 1 0 4/4 Enable / disable defog.
wdr_mode 0~2 1 4/4 WDR enhanced.
0: off
1: manual
2: auto
wdr_ compensation 0~2 1 4/4 WDR strength
