For Cable or Satellite Boxes with DVI:
1. Turn off the power to the LCD HDTV and HDTV
Set-Top Box.
2. Using a HDMI-DVI cable, connect the DVI end to
your HDTV Set-Top Box and the HDMI end to the
HDMI2 Input at the side of the LCD HDTV.
3. Using an audio cable (1/8’ stereo connector on the
going into the TV), connect the cable to the
audio output connectors associated with the
DVI output on your HDTV Set-Top Box and
connect the other end to the audio
associated with the RGB input
at the rear of the LCD HDTV.
4. Turn on the power to the LCD
HDTV and HDTV Set-Top Box.
5. Select HDMI2 using the INPUT button on the remote or side of the LCD HDTV, or directly by
pressing the HDMI button on the Remote Control.
Note:
• The HDMI input on the LCD TV supports High-bandwidth Digital Content Protection (HDCP).
HDCP encrypts the transmission between the video source and the digital display for added
security and protection.
• If you are already using the HDMI2 input for another component, or you do not want to use the
HDMI2 input for the Set-Top Box, you can connect the Set-Top Box to the HDMI1, HDMI3 or
HDMI4 connection. The LCD TV will recognize the DVI connection and obtain audio information
from the audio connectors on the rear of the TV.
• Refer to your HDTV Set-Top Box user manual for more information about the video output
requirements of the product or consult your cable or satellite operator.
