VIZIO M470NV/M550NV User Manual
Version 6/28/2010 11
www.VIZIO.com
Wall Mounting your HDTV
Your HDTV can be mounted on the wall for viewing. If you choose to mount your HDTV on the wall, follow
the instructions below.
1. Write down the serial number located on the back of your HDTV in the space provided on page 1 to
have it handy if you need to call for support.
2. Remove the stand base and neck:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft, flat surface
to prevent damage to the screen.
c. Remove the screw holding the stand neck, and
then remove the neck and base.
Note: To remove the base from the neck, unscrew thumbscrew on
bottom.
3. Mount your HDTV on the wall:
a. Attach your HDTV to a wall mount (sold
separately) using the mounting holes in the back
panel of your HDTV.
b. Read the instructions that came with your specific
wall mount to properly hang your HDTV.
M470NV Wall Mounting Specifications
Screw Size M6
Screw Length 20.0 mm
Screw Pitch 1.0 mm
Hole Pattern
VESA standard 200 x 200
mm spacing
M550NV Wall Mounting Specifications
Screw Size M8
Screw Length 20.0 mm
Screw Pitch 1.25 mm
Hole Pattern
VESA standard 400 x 200
mm spacing
