VIZIO VOJ320F1A User Manual
Version 8/25/2008 26
www.VIZIO.com
2.6 Connecting Your VCR or Video Camera
1. Turn off the HDTV and VCR or Video
Camera.
2. Connect the S-Video jack on the rear of
your VCR or Video Camera to the S-
Video jack in the AV input (yellow/red
area) at the rear of the HDTV.
3. Connect an audio cable (white
and red connectors) cable to the
audio output connectors
associated with the S-Video output on your VCR or Video Camera and connect the other end
to the audio connectors associated with the AV input (yellow/red area) at the rear of the
HDTV.
4. Turn on the power to the HDTV and VCR or Video Camera.
5. Select AV using the INPUT button on the remote or side of the HDTV, or directly by pressing
the AV button on the Remote Control.
Note: Refer to your VCR or Video Camera user manual for more
information about the video output requirements of the product.
