19
Battery
Fuse
+
Switch
PREDATAIR60
Battery
F
use or c
i
rcu
i
t
b
rea
k
er
(separate or built into switch)
30A
PREDATAIR60
Remote switch
see table 1 for correct wire gauge
*
**
*
Ground to chassis or back
to battery negative termina
l
Red
Green
Figure 14 – Direct actuating alternative
This is a more functional method for direct power wiring as the
current carrying wires are much shorter.
