Vogt
®
VT Service Manual 4-3
Initial Startup
FIGURE 4-4
Service and Ball Valve Locations
VT40
Compressor Suction
Service Valve
Hot Gas Line Ball Valve
Receiver Service Valve
Compressor Discharge
Service Valve
VT60
Compressor Suction
Service Valve
Hot Gas Line Ball Valve
Receiver Service Valve
Compressor Discharge
Service Valve
Liquid Line Ball Valve
Liquid Line Ball Valve
