Void Nexus Series - Nexus XL Technical Specifications; Nexus XL Physical Dimensions

Page 7
UG10578-2.0 - Nexus XL User Guide V2.0
3 About
3.4 Nexus XL specifications
Frequency response 30 Hz - 150 Hz ±3dB
Eciency
1
104 dB 1W/1m
Nominal impedance 8 Ω
Power handling
2
2000 W AES
Maximum output
3
135 dB cont, 141 dB peak
Driver configuration 1 x 21”
Dispersion Array dependant
Connectors 2 x 4-pole speakON™
Height 754 mm (29.7”)
Width 738 mm (29”)
Depth 860 mm (33.9”)
Weight 90 kg (198.4 lbs)
1
Measured in half space
2
AES2 - 1984 compliant
3
Calculated
3.5 Nexus XL dimensions
738 (29.1”)
738 (29.1”)
860 (33.9”)
867.27 (34.2”)
754 (29.7”)
738 (29.1”)
860 (33.9”)
860 (33.9”)
738 (29.1”)
Figure 3.1: Dimensions
