Void Nexus Series - Nexus XL Wiring Diagram; Bias Q5 SpeakON Wiring

Page 9
UG10578-2.0 - Nexus XL User Guide V2.0
4 Cable and Wiring
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
In
Out/Link
+
-
21” LF
4.4 Nexus XL wiring diagram
speakON
TM
pins 1+/1- speakON
TM
pins 2+/2-
In LF (21”) Out/link
Out LF link Out/link
Figure 4.2: Wiring diagram
4.5 Bias Q5 speakON
TM
wiring
LF 1+
LF 1-
LF 1+
LF 1-
Figure 4.3: Bias Q5
Bias Q5 Channel 1
Output LF (12”)
Max parallel units 4 (2 Ω load to amplifier)
