Voith BTS-Ex - Initiator, Mounting Flange; Evaluator

BTS
-Ex, non-contacting thermal switch unit
Spare Parts Information
Installation and Operating Manual / Version 7 / 3626-019600ex en / Protection class
0: public / 2020-07-15
44
13.2 Initiator, mounting flange
Type of initiator
Material No.
NJ 10-22-N-E93-Y30629-70
TCR.10678650
NJ 10-22-N-E93-Y30627-100
TCR.10678670
NJ 10-22-N-E93-Y106925
TCR.11960550
NJ 10-22-N-E93-Y245590
(new design, cable length 2 m)
1)
201.02171810
NJ 10-22-N-E93-Y246868
(new design, cable length 5 m)
1)
201.02171910
NJ 10-22-N-E93-Y246869
(new design, cable length 10 m)
1)
201.02172010
Mounting flange BF22
TCR.03668170
Table 15
1 New design with permissible ambient temperature from -40 °C to 100 °C.
The initiators differ only regarding the various cable length.
13.3 Evaluator
Type of evaluator
Material No.
KFD2-SR2-Ex2.W.SM
TCR.11975610
KFD2-SR2-Ex2.W.SM (new Ex marking)
201.03905210
Table 16
