Fig. 11
4.1 DELIVERY
Due to the weight of the appliance it may be necessary for
two people to lift and attach the appliance to its mounting. The
appliance is contained within a heavy-duty cardboard carton.
4.2 CONTENTS
Contained within the carton is:
• the boiler
• the wall bracket
• carton template
• an accessories pack containing appliance service connections
and washers
• the instruction pack containing the installation, servicing & user
instructions, guarantee registration card and a 3-amp fuse.
4.3 UNPACKING
At the top of the carton pull both sides open – do not use a
knife – unfold the rest of the carton from around the appliance,
carefully remove all protective packaging from the appliance and
lay the accessories etc. to one side. Protective gloves should
be used to lift the appliance, the appliance back-frame should
be used for lifting points.
4.4 PREPARATION FOR MOUNTING THE AP-
PLIANCE
The appliance should be mounted on a smooth, vertical, non-
combustible surface, which must be capable of supporting the
full weight of the appliance. Care should be exercised when
determining the position of the appliance with respect to hidden
obstructions such as pipes, cables, etc.
When the position of the appliance has been decided – using
the template supplied – carefully mark the position of the wall-
4.5 FITTING THE FLUE
-
4.5.1 CONCENTRIC HORIZONTAL FLUE
The appliance can be used with either the Vokèra condensing
NOTE
These instructions relate only to the Vokèra condensing
may be extended from the outlet elbow in the horizontal plane
(see 2.9). A reduction must also be made to the maximum length
(see table below) when additional bends are used.
Reduction for additional bends
45º bend 1.3 metre (60/100) - 1.0 metre (80/125)
90º bend 1.6 metre (60/100) - 1.5 metre (80/125)
Part No. Description Length
522 Plume management kit 1370mm
29450123 90-degree bend N/A
29450124 45-degree bends (pair) N/A
29450125 500mm extension 500mm
29450126 1000mm extension 1000mm
29450127 2000m extension 2000mm
29450128 Telescopic extension 372/519mm
529 Wall bracket pack (5) 208mm
Using the template provided (A), mark and drill a 125mm hole
wall-mounting bracket should now be drilled and plugged, an
that the bracket is mounted securely. Once the bracket has
been secured to the wall, mount the appliance onto the bracket.
FITTING THE TELESCOPIC HORIZONTAL FLUE KIT
In some instances It may necessary to cut the inner 60mm pipe
FITTING THE HORIZONTAL FLUE KIT
Carefully measure the distance from the centre of the appliance
X). Add 65mm to dimension X to give you Dimension Y (see
-
seal is made. Using the clamp, gasket, and screws supplied,
NOTE
-
-
cement or a suitable alternative that will provide satisfactory
SECTION 4 - INSTALLATION
Fig. 10
A
Terminal or
extension
Outer clamps
