Mandatory Replacement Parts
♦ Bolts - Camshaft Adjustment Valve 1
♦ O-ring - Camshaft Adjustment Valve 1
♦ Seal - Camshaft Adjustment Valve 1
Removing
– Remove the engine cover. Refer to
⇒ 3.1 Engine Cover, Removing and Installing, page 38 .
– Unclip the coolant and fuel lines and set them aside.
– Disconnect the connector -1- from the Camshaft Adjustment
Valve 1 - N205- .
– Remove the bolts -arrows- and then the Camshaft Adjustment
Valve 1 - N205- -2-.
Installing
Install in reverse order of removal. Note the following:
Note
Replace seals and O-rings.
– Lubricate seals on the Camshaft Adjustment Valve 1 - N205- /
Exhaust Camshaft Adjustment Valve 1 - N318- sealing surfa‐
ces with engine oil.
Tightening Specifications
♦ Refer to ⇒ 2.1 Overview - Timing Chain Cover, page 104 .
4.4 Camshaft Adjustment Valve 1 - N205-
and Exhaust Camshaft Adjustment
Valve 1 - N318- , Removing and Instal‐
ling
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Bolts - Camshaft Adjustment Valve 1
♦ O-ring - Camshaft Adjustment Valve 1
♦ Seal - Camshaft Adjustment Valve 1
♦ Bolts - Exhaust Camshaft Adjustment Valve 1
♦ O-ring - Exhaust Camshaft Adjustment Valve 1
♦ Seal - Exhaust Adjustment Valve 1
Removing
– Remove connector -1- from Exhaust Camshaft Adjustment
Valve 1 - N318- and connector -3- from Camshaft Adjustment
Valve 1 - N205- .
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
4. Valvetrain 161
