Display details and symbols
REL symbol for relative value measurement (= reference measure-
ment)
auto stands for „automatic measuring range selection“
HOLD Displayed with active hold function
Battery replacement symbol; please replace the batteries imme-
diately to avoid measuring errors.
Symbol for the diode test
Symbol for the acoustic continuity checker
AC Alternating magnitude for voltage and current
DC Commensurability for voltage
OL Overload display when exceeding the measuring range
mV millivolt (exp.-3)
V Volt (unit of electric potential)
A ampere (unit of electric current)
Hz Hertz (unit of frequency)
kHz Kilohertz (exp.3)
Ω Ohm (unit of electric resistance)
kΩ kiloohm (exp.3)
MΩ megaohm (exp.6)
nF Nanofarad (unit of electric capacity, exp.-9, symbol )
µF Microfarad (exp.-6)
°C Degrees centigrade
°F Degrees Fahrenheit
36
