Capacity, overload protection 600 V
Range Accuracy Definition
40.00 nF ±(4,5% + 30) 0.01 nF
400.0 nF 0.1 nF
4,000 µF ±(3,5% + 15) 1 nF
40.00 µF 0.01 µF
400.0 µF ±(4% + 20) 0.1 µF
4000 µF ±(5% + 20) 1 µF
Temperature (measuring device without sensor accuracy only)
Range Accuracy Definition
0.0 to +760 °C ±(3% + 30) 0.1 °C
Frequency, overload protection 600 V
Range Accuracy Sensitivity
10 Hz - 10 kHz ±(1,5% + 5) 15 Vrms
Acoustic continuity tester <70 Ω
Diode test voltage: 2.8V (open measurement cycle)/ test current:
approx. 0.9 mA
Diode overload protection/continuity tester: 600 V
<Do not exceed the maximum permitted input values. Do not
touch any circuits or parts of circuits, if they can have higher
voltages than 25 V Acrms or 35 V DC. Mortal danger!
