Technical data and measuring tolerances
Technical Data
Display reading. . . . . . . . . . . . . 3400 (VC-86), 2000 (VC-82) counts
Input resistance . . . . . . . . . . . . approx. 10MOhm
Batteries . . . . . . . . . . . . . . . . . . 2x 1.5 V button cells LR44 / AG13
Current consumption . . . . . . . . approx. 2 mA
Operating period . . . . . . . . . . . approx. 80 h
Working temperature . . . . . . . . 0°C to 40°C
Storage temperature . . . . . . . . -10°C to 50°C
Rel. humidity. . . . . . . . . . . . . . . < 75% (non-condensing)
from 0 to 30°C
Working height . . . . . . . . . . . . . up to a max. of 2 000 m through NN
Temp. for gar. accuracy . . . . . . +18°C to +28°C
Weight incl. battery . . . . . . . . . approx. 140 g
Dimensions (LxWxH) . . . . . . . . 230 mm x 35 mm x 20 mm
Measurement tolerances
Statement of accuracy in ± (% dof reading+ display error in digits (=
dgt = no. of the smallest points)). The accuracy is valid for 1 year at
a temperature of +23°C +/5°C, and at a relative humidity of less than
75 %, non-condensing.
Type of operation DC Volt
Range VC-82 Range VC-86 Accuracy Resolution
200,0 mV 400,0 mV ± (1,0% + 4 dgt) 0,1m V
2,000 V 4,000 V ± (1,3% + 3 dgt) 0,001 V
20,00 V 40,00 V ± (1,3% + 3 dgt) 0,01 V
200,0 V 250 V ± (1,3% + 3 dgt) 0,1 V
250 V - ± (1,5% + 3 dgt) 1 V
Overload protection 250 V; input resistance: 10 MΩ"
Type of operation AC Volt (40Hz to 400Hz)
Range VC-82 Range VC-86 Accuracy Resolution
200,0 mV - ± (1,8% + 40 dgt) 0,1mV
