VOLTCRAFT vc170 User Manual

(5 – 100% of the
measuring range)
(5 – 100% of the
measuring range)
44
Direct voltage, overload protection 250 V
Range Accuracy Resolution Range Accuracy Resolution
VC130/150 VC170
200 mV 0.1 mV 400 mV* ±(0,8% + 8) 0.1 mV
2,000 mV 1 mV 4,000 mV 1 mV
20 V
±(0.5% + 8)
0.01 V 40 V ±(0,8% + 8) 0.01 V
200 V 0.1 V 250 V 0.1 V
250 V ±(0,8% + 8) 1 V * With the VC170, the 400 mV measuring range
is only available via the manual measuring range
selection.
Alternating voltage (40 – 400 Hz), overload protection 250 V
Range Accuracy Resolution Range Accuracy Resolution
VC130/150 VC170
200 V
±(1,5% + 8)
0.1 V 400 mV* ±(2,0% + 10) 0.1 mV
250 V 1 V 4,000 mV 1 mV
40 V ±(1,6% + 4) 0.01 V
250 V 0.1 V
* With the VC170, the 400 mV measuring range
is only available via the manual measuring range
selection.
Direct current, overload protection 1A/250V + 10 A/250 V
Range Accuracy Resolution Range Accuracy Resolution
VC130 VC170
200 µA* 0.1 µA 400 µA ±(1,3% + 2) 0.1 µA
2000 µA ±(1,3% + 2) 1 µA 4,000 µA 1 µA
20 mA 0.01 mA 40 mA ±(1,6% + 2) 0.01 mA
200 mA ±(1,5% + 8) 0.1 mA 400 mA 0.1 mA
10 A ±(2,5% + 10) 0.01 A 4 A ±(2,0% + 10) 0.01 A
* only with the VC130 10 A 0.1 A
Alternating current (only with VC170), overload protection 1A/250V + 10 A/250 V
Range (40 - 400 Hz) Accuracy Resolution
400 µA
±(1.6% + 5)
0,1 µA
4,000 µA 1 µA
40 mA
±(2.0% + 8)
0.01 mA
400 mA 0.1 mA
4 A
±(2.6% + 4)
0.001 A
10 A 0.01 A
