45
Resistance, overload protection 250 V, test voltage ca. 0.5 V
Range Accuracy Resolution Range Accuracy Resolution
VC130/150 VC170
200 Ω 0.1 Ω 400 Ω ±(1.6% + 3) 0,1 Ω
2000 Ω 1 Ω 4 kΩ 0.001 kΩ
20 kΩ
±(1.0% + 10)
0.01 kΩ 40 kΩ ±(1.3% + 2) 0.01 kΩ
200 kΩ 0.1 kΩ 400 kΩ 0.1 kΩ
20 MΩ ±(1.3% + 7) 0.01 MΩ 4 / 40 MΩ ±(2.0% + 8) 0.001 / 0.01 MΩ
Temperature (only VC150)
Range Accuracy Resolution
-40 to 0 °C ±(10,4% + 7) 1 °C
>0 to 400 °C ±(3,3% + 4)
>400 to 1,000 °C ±(3,9% + 4)
Frequency/duty cycle (only with VC170), overload protection 250 V
Range Accuracy Resolution
10 Hz - 10 MHz 0.01 Hz - 0.01 MHz
max. 10 Vrms Sensitivity:
±(0,7% + 4) < 100 kHz = 300 mV
> 100 kHz = 600 mV
0,1 – 99,9% 0,1%
Acoustic continuity tester <10 Ω Permanent sound
Diode test test voltage: Uo 3.0 V
Diode overload protection/continuity tester: 250 V
Transistor test “hFE” 0 – 1000ß, test voltage Uce 3 V, test current Ibo 10 µA
NCV voltage test 230 V/AC
Do not exceed the maximum permitted input values. Do not touch any circuits or
parts of circuits, if they can have higher voltages than 25 V Acrms or 35 V DC. Mortal
danger!
