Technical Data
Engine
Product sales designation D1-13 D1-20 D1-30 D2-40
Crankshaft power, kW* 9.0 13.8 20.9 29.1
Propeller shaft, power, kW* 8.6 13.3 20.1 27.9
After sales designation D1-13 F D1-20 F D1-30 F D2-40 F
Swept volume, l 0.51 0.76 1.13 1.51
No. of cylinders 2 3 3 4
Cylinder diameter/stroke, mm 67/72 67/72 77/81 77/81
Compression ratio 23.5:1 23.5:1 23.5:1 23.5:1
Engine revolutions, rpm 2800-3200 2800-3200 2800-3200 2800-3200
Idle revolutions, rpm 850 ±25 850 ±25 850 ±25 850 ±25
Direction of rotation (seen from front) Clockwise Clockwise Clockwise Clockwise
Max. permissible rearward inclination in
operation
20° 20° 20° 20°
Max. side inclination in operation 30° 30° 30° 30°
Weight, engine less oil and water 96 kg 118 kg 127 kg 148 kg
* According to ISO 8665
47711262 01-2019 © AB VOLVO PENTA 79
