Volvo Penta D3 - Page 115

1
4
2
3
P0002510
Removing the propeller
1 Undo the aft propeller nut (1) and remove the aft
propeller (2).
2 Remove the forward propeller nut (3) and
remove the forward propeller (4).
3 Wipe the propeller shaft clean.
Installation
1 Thoroughly lubricate the propeller hub and pro-
peller shaft with Volvo Penta grease (part #
828250).
2 Fit the forward propeller (4).
3 Install the forward propeller nut (3) and torque to
60 Nm.
4 Install the aft propeller (2).
5 Install the forward propeller nut (1) and torque to
100 Nm (75 ft.lbs.).
6 Turn the shift lever to the neutral position. Attach
the wire to the shift arm. Install a new cotter pin.
7 Install the cover and bolt it in place.
8 Check that the propeller can be turned easily.
Maintenance
47705992 05-2015 © AB VOLVO PENTA 113
