Coolant pump / Fuel pump
1
2
3
P0003681
Adjust
1 Loosen screws (1) and (2).
2 Push the fuel pump (3) to the left until the belt is
correctly tensioned.
3 Tighten the screws.
Replace
1 Loosen screws (1) and (2).
2 Push the fuel pump (3) to the right.
3 Remove the belt and replace it with a new one.
4 Push the fuel pump (3) to the left until the belt is
correctly tensioned.
5 Tighten the screws.
Maintenance
