Drive belt, compressor
The compressor is driven by a poly-vee belt by the
engine flywheel. The belt has an automatic belt ten-
sioner; manual adjustment of belt tension is therefore
not required.
Compressor, oil
Follow the recommended oil change interval, see
Maintenance Schedule page 72
.
Compressor, oil change
1 Clean the area around the drain plug and filling hole
to avoid dirt getting into the system when changing
oil.
2 Remove the filling hole plug (1).
3 Have a container ready to avoid oil spillage.
Remove the drain plug (2) and let the oil run out.
4 Replace the drain plug.
5 Fill with oil. Oil quantity and grade, see Technical
Data, Lubrication System.
6 Replace the filling hole plug.
Maintenance
47702095 04-2011 77
