Instrument cluster
Symbol Meaning
Next stop
Seat belt reminder
Parking brake applied
Battery charging fault
Pre-heating activated
Emission values too high
Window/mirror heater
activated
Symbol Meaning
Differential lock is engaged
Bogie lifted
Door brake activated
Kneeling activated (for
easier access)
Check the tachograph
Fault in ABS system
Clogged particulate filter
Symbol Meaning
High exhaust temperature
Fault in braking system
Air pressure for primary
braking system is lower
than 6 bar
Air pressure for secondary
braking system is lower
than 6 bar
ESP (Electronic Stability
Program) enabled
Fault in Lane Keeping
Support (LKS)
SCR fluid low
