Destination sign
• Departure time
• BOX function
1 To enter the route selection mode,
press OK button (4).
2 Press the Right (7) button until
selecting the wanted setting.
3 To enter the wanted setting, press
the OK button.
4 Use the up (3) or down button (6) to
increase or decrease the value of the
digit.
5 To move between the digits to be
changed, use the left (2) and right
buttons.
6 After selecting the desired
destination, press the OK button to
confirm and send destination
information to the signs.
7 This operation completes in 3
seconds. To cancel and keep the
previous information, press Cancel
button (5).
To change the route direction, access
the route selection mode.
Press Up (3) or Down (6) button for
about 3 seconds until the route direction
message is displayed in the control unit.
To change the route direction, first the
destination file must be prepared for this
function.
Service menu
To access the service menu, press the
OK button (4).
To access the menu, press the Left (2)
button. To enter the menu, press the OK
button (4).
After accessing the control unit menu,
use the left (2), right (7), up (3) or down
button (6) to navigate the menu
functions.
To exit menu function, press the Cancel
button (5).
Settings can be made for:
• Language
• Time and date
• Control unit panel
• Compatible with Sl/SLE family
• Compatible with 100FS, 200CF
• Display brightness
• Roundtrip route configuration
• Rebooting the control unit
Updating destination sign
information
The USB socket is located on the right
side of the unit. Plug in the USB flash
drive. A short message on the screen
shows that the USB device is
recognised.
To select the required file, press Up (3)
or Down (6) button, thus changing the
file to be selected. To confirm, press the
OK button (4), or Cancel button (5) to
cancel the upload.
During file update, the unit shows a
progress bar.
When the unit has finished loading the
update, you are prompted to remove the
USB flash drive and it returns to the
route selection mode.
CAUTION
Do not remove the USB flash drive or turn
off the power supply while uploading data.
It corrupts the update file and can lead to
malfunction.
Updating firmware
To update the firmware, insert the USB
flash drive while the control unit is turned
off or during rebooting.
The firmware update is automatic. When
finished, remove the USB flash drive.
When the USB flash drive is removed,
the unit restarts with the new firmware.
