Group 30: Electrical system Wiring diagram
Pin configuration, MDI
Multi link
1 CAN L
2 CAN L
3 CAN H
4 Multilink negative supply
5 CAN H
6 Multi link power supply
Engine harness
1 Battery negative
2 Flywheel sensor +
3 Flywheel sensor -
4 Stop solenoid
5 Coolant temperature sensor
6 Oil pressure switch
7 Excitation
8 Not used
Button panel
1 Stop
2 On / Off
3 Ack / Dim
4 Battery negative
5 Start / Preheat
6 Buzzer
