Volvo EC18E - Lubrication and Service Chart

is continuous with fixed intervals. The operating
time between intervals only applies if the machine
is used in normal environment and operating
conditions. Ask your Volvo dealer what is right for
your specific machine.
Service points
Service positions rear, left side and right side.
1
2
3
4
4
7
6
5
13
14
8
9
10
11
12
V1195982
15
1 Fuel prefilter / water separator
2 Fuel filter
3 Fuel filler neck
4 Engine oil filler necks (two)
5 Expansion tank
6 Engine oil dipstick
7 Engine oil filter
8 Hydraulic oil filter
9 Hydraulic oil level sight glass including filler neck and filter
10 Hydraulic oil tank
Maintenance
149
