Machine view
V1200432
1
2
3
4 5
7
6
9
8
10111214
15
13
1 Bucket 9 Travel motor
2 Bucket cylinder 10 Undercarriage
3 Dipper arm 11 Tracks
4 Dipper arm cylinder 12 Superstructure
5 Boom 13 Boom offset cylinder
6 Boom cylinder 14 Dozer blade
7 Working lights 15 Dozer blade cylinder
8 Rear hood (Engine hood)
