Fuse Ampere Function
FU06 10 A Hydraulic functions
V-ECU
(a)
Auto idle
(a)
FU07 5 A Alternator
I-ECU
Fuel filling pump
FU08 10 A Fuse, hydraulic safety valve,
control lock (safety lock)
Hydraulic functions
FU09 20 A Main relay, working lights
FU10 10 A Hydraulic functions
FU11 10 A Cab fan
FU12 10 A Windscreen wiper and washer
FU13 5 A Instrument cluster supply
FU14 10 A Hydraulic functions
Rotating warning beacon, green
FU15 7.5 A
Radio equipment
(b)
, interior light
(b)
FU16 15 A Power outlet, horn
Combined switch (right joystick)
(b)
FU17 10 A Rotating warning beacon
FU18 10 A A-ECU, W-ECU, Hydraulic safety
FU19 10 A A-ECU, W-ECU
a) only Standard machines with electronic
b) optional equipment
NOTE!
Use only fuses of specified capacity (Ampere
rating).
194
Specifications
Electrical system
