Symbol key
These standard symbols are used in the Lubrication
and service chart, see the adjacent table.
1 Engine oil 2 Grease lubrication 3 Swing drive gear oil
change
4 Swing drive gear oil
check
5 Track drive gear oil
check
6 Track drive gear oil
change
7 Hydraulic oil 8 Hydraulic oil level 9 Hydraulic oil filter
10 Hydraulic tank, air
breather filter
11 Fuel filter 12 Water separator
13 Engine, coolant 14 Engine, coolant filter 15 Engine coolant level
16 Engine oil level 17 Engine oil filter 18 Operator manual
19 Air cleaner filter
250
Maintenance
Lubrication and service chart
