Service capacities and change
intervals
Change capacities
Oils and other liquids Change capacities
Engine oil, including filter 11 litres (2.9 US gal.)
Coolant 10 litres (2.6 US gal.)
Hydraulic tank 76 litres (20 US gal.)
Hydraulic system, total 120 litres (32 US gal.)
Track gearbox (each) 0.8 litres (0.2 US gal.)
Fuel tank 105 litres (27.7 US gal.)
Swing ring gear 6 litres (1.6 US gal.)
5.4 kg (11.9 lb)
Specifications
Service capacities and change intervals
309
