Control pedals
Travel pedal Angle 12.4°
Operating force 10 Nm (1.02 kgf m) (7.4 lbf ft)
Control levers
- One button type
- One (or two)
button with
proportional switch
type
Angle Forward and backward: 25°
Right and left: 19°
Operating force Forward and backward: 2.07 Nm (0.21 kgf m)
(1.53 lbf ft) at 3.2 MPa
Right
and left: 1.88 Nm (0.19 kgf m) (1.39 lbf ft)
Track motor
Type Variable displacement axial piston motor with mechanical
brake
Relief valve setting pressure 22.6 MPa (230 kgf cm²) (3270 psi)
Brake type Multi-disc, spring applied, hydraulic released
Track gearbox
Type 2-stage planetary
Swing motor
Type Fixed displacement axial piston motor with mechanical
brake
Relief valve setting pressure 19.6 MPa (200 kgf cm²) (2850 psi)
Swing gearbox
Type 2-stage planetary
316
Specifications
Hydraulic system
