Trailer hi tch for drawbar eye 40 mm
Grease the lubrication nipples (1) and the coupling pin with the
drawbar eye seat (2) in regular intervals according to the condition
of use and after each cleaning with pressure washers.
NO
T
T
E
E
!
!
If the trailer hitch with 40 mm drawbar eye is mounted on the
outrigger, grease also the cam plate (3).
Tr
a
a
i
i
l
l
e
e
r
r h
i
i
t
t
c
ch f
o
o
r
r d
r
r
a
a
w
w
b
b
a
a
r
r e
y
ye 5
0
0 m
m
m
Grease the coupling pin (1) with the support ring (2), the bearing
(3) and the lower funnel bearing (4) in regular intervals according
to the condition of use and after each cleaning with pressure
washers.
V1127298
1
2
1
3
Greasing of trailer hitch for drawbar eye 40 mm
1 Lubrication nipple
2 Drawbar eye seat
3 Cam plate
Greasing of trailer hitch for drawbar eye 50 mm
(trailer hitch for blade)
1 Coupling pin
2 Support ring
3 Lubrication nipple, bearing
4 Lubrication nipple, lower funnel bearing
